special_functions_gbl Module Reference

Data Types
interface	cfp_9gmic
interface	cfp_9gmit
interface	cfp_9lgic
interface	cfp_9lgit
interface	cfp_9lgmc
interface	cfp_besi
interface	cfp_besj
interface	cfp_binom
interface	cfp_csevl
interface	cfp_eval_poly_horner
interface	cfp_gamic
interface	cfp_gamlm
interface	cfp_gamma_fun
interface	cfp_gamma_slatec
interface	cfp_initds
interface	cfp_lgams
interface	cfp_lngam
interface	cfp_lnrel
type	real_harmonics_obj
	Object used to evaluate real spherical and solid harmonics. More...

Functions/Subroutines
elemental integer function, public	ipair (i)
	This function is used to index an ordered pair of values (i,j), where i .ge. j, i .ge. 1. The index of the ordered pair is: ipair(i) + j. This process of indexing can be used in a nested way to index quartets of integers, say (i,j,k,l). We compute ij = ipair(i)+j and kl = ipair(k)+l. The index of the quartet (i,j,k,l) is: ipair(ij)+kl. We assume that i.ge.j, k.ge.l, ij.ge.kl. This nesting (triangularization) is used heavilly to index the 2-particle symmetric integrals.
subroutine, public	unpack_pq (pq, n, p, q)
	Assuming \( pq = p + (q-1)*n \) this routine returns p,q given pq,n.
subroutine, public	cfp_nlm (inorm, l)
subroutine, public	cfp_resh (sh, x, y, z, l)
subroutine, public	cfp_solh (sh, x, y, z, l)
subroutine, public	cfp_zhar (sh, x, y, z, l)
real(kind=ep1) function, dimension(1:mmax+1), public	boys_function_quad (t, mmax)
	Quadruple precision version of boys_function. See boys_function for details on the method of evaluation.
subroutine, public	cfp_eval_poly_horner_many (n, x, n_x, a, res)
	This subroutine evaluates a set of polynomials of degree \(n\) at a number of points \(x\) using the Horner form for polynomials.
subroutine, public	cfp_sph_to_cart_mapping (l, m, c, i_exp, j_exp, k_exp)
	This routine constructs for a given real solid harmonic L,M the list of cartesian functions which build up this real solid harmonic. On output the array c(:) contains the coefficients with which the individual cartesians contribute to the solid harmonic. Exponents of the cartesians are then given in the arrays i_exp,j_exp,k_exp.
subroutine, public	cfp_sph_shell_to_cart_shell (l, c)
	This routine constructs for a given real solid harmonic L the matrix of coefficients for all M of the transformation from the cartesian harmonics (~x^i*y^j*z^k, i+j+k=L). On output the linear array c(:) emulates 2D matrix with 2*L+1 rows and (L+1)*(L+2)/2 columns. The rows of c correspond to the M values: -L,-L+1,...,0,1,...,L. The coefficients in each row are ordered so that the n-th coefficient in the given row of c corresponds to the coefficient for the cartesian harmonic with the shell canonical index n.
subroutine, public	cfp_sph_shell_to_cart_lshells (l, nz, c_nz, nz_can)
	This routine constructs for all real solid harmonic with L .le. l the matrix of coefficients for all M of the transformation from the cartesian harmonics (~x^i*y^j*z^k, i+j+k=L). On output the linear array c(:) emulates 2D matrix with 2*L+1 rows and (L+1)*(L+2)/2 columns. The rows of c correspond to the M values: -L,-L+1,...,0,1,...,L. The coefficients in each row are ordered so that the n-th coefficient in the given row of c corresponds to the coefficient for the cartesian harmonic with the shell canonical index n.

Function/Subroutine Documentation

boys_function_quad()

real(kind=ep1) function, dimension(1:mmax+1), public special_functions_gbl::boys_function_quad	(	real(kind=ep1), intent(in)	t,
		integer, intent(in)	mmax )

Quadruple precision version of boys_function. See boys_function for details on the method of evaluation.

Here is the call graph for this function:

cfp_eval_poly_horner_many()

subroutine, public special_functions_gbl::cfp_eval_poly_horner_many	(	integer, intent(in)	n,
		real(kind=cfp), dimension(n_x), intent(in)	x,
		integer, intent(in)	n_x,
		real(kind=cfp), dimension(n_x,n+1), intent(in)	a,
		real(kind=cfp), dimension(n_x), intent(out)	res )

This subroutine evaluates a set of polynomials of degree \(n\) at a number of points \(x\) using the Horner form for polynomials.

Parameters

[in]	n	Order of the polynomials.
[in]	x	Array of points at which to evaluate.
[in]	n_x	The number of points (dimension of x).
[in]	a	The array of the coefficients a(1:n_x,1:n+1): different for each point x.
[out]	res	The polynomials evaluated at points x.

cfp_nlm()

subroutine, public special_functions_gbl::cfp_nlm	(	real(kind=cfp), dimension(-l:l,0:l), intent(out)	inorm,
		integer, intent(in)	l )

Purpose:

 !> Calculate the full set of inverse normalization factors Ilm for the real unnormalized solid spherical harmonics with l,m .le. L using recursion.
 !> The unnormalized solid spherical harmonics are defined in Rico, Lopez, et al. Int. J. Q. Chem.,2012,DOI:10.1002/qua.24356.
 !>

\[ I_{lm} = \frac{1}{N_{lm}} = \sqrt{\frac{2\pi(1+\delta_{m,0})}{2l+1}\frac{(l+|m|)!}{(l-|m|)!}}. \]

Todo

{add error checking for case l > size(INorm(,:))}

 !>  Nlm is the normalization factor for the real unnormalized solid spherical harmonics zlm.
 !>

Parameters

[out]	INorm	!> Real array (-L:L,0:L) containing the values of the inverse normalization factors Ilm for all l .le. L and the corresponding values of m. !>
[in]	L	!> Integer angular momentum of the last Ilm to be generated. !>

cfp_resh()

subroutine, public special_functions_gbl::cfp_resh	(	real(kind=cfp), dimension(-l:l,0:l), intent(out)	sh,
		real(kind=cfp), intent(in)	x,
		real(kind=cfp), intent(in)	y,
		real(kind=cfp), intent(in)	z,
		integer, intent(in)	l )

Purpose:

 !> Calculate the full set of real normalized spherical harmonics with l,m .le. L using recursion. See Helgaker, p.210, p.215-218 (Section 6.4) for details.
 !> The real spherical harmonics are related to the solid ones using the formula:
 !>

\[ X_{lm}(\Omega) = S_{lm}(x/r,y/r,z/r)\sqrt{\frac{2l+1}{4\pi}}. \]

We define the normalization factor:

\[ n_{lm} = \sqrt{\frac{2l+1}{4\pi}} \]

and then use Helgaker's method to calculate the 'scaled' solid harmonics:

\[ X_{lm}(\Omega) = {\overline{S}_{lm}}(x/r,y/r,z/r)=n_{lm}S_{lm}(x/r,y/r,z/r). \]

 !> The real spherical harmonics defined in this way are equivalent to the real spherical harmonics defined using the standard formula:
 !>

\[ X_{lm}(\Omega) = \begin{cases} {\sqrt{2}}(-1)^{m}{\cal{R}}\left(Y_{l\vert m\vert}(\Omega)\right), m>0 \\ {\sqrt{2}}(-1)^{m}{\cal{I}}\left(Y_{l\vert m\vert}(\Omega)\right), m<0 \\ Y_{l0}(\Omega), m=0, \end{cases} \]

where the complex spherical harmonics \(Y_{lm}(\Omega)\) satisfy the Condon-Shortley phase convention. Note that the convention of Homeier and Steinborn is not to include the factor (-1)**m in the definition of the real spherical harmonics. However, here we follow the std. definition and include the factor (-1)**m in the definition of the real spherical harmonics.

Todo

{add error checking for case L > size(SH(,:))}

Parameters

[out]	SH	!> Real array (-L:L,0:L) containing the values of the spherical harmonics for all l .le. L and the corresponding values of m. !> According to my tests the results are in vast majority of cases accurate to full REAL(kind=cfp). In only a few cases the precision in the last 1 or 2 digits is lost. !>
[in]	X,Y,Z	!> Real input coordinates for which the real harmonics will be evaluated. !> The radius vector r={X,Y,Z} need not be normalized to 1 since this is done automatically during the calculation. !>
[in]	L	!> Integer angular momentum of the last spherical harmonic to be generated. For L = 0; SH = 1/sqrt(4*pi) !>

cfp_solh()

subroutine, public special_functions_gbl::cfp_solh	(	real(kind=cfp), dimension(-l:l,0:l), intent(out)	sh,
		real(kind=cfp), intent(in)	x,
		real(kind=cfp), intent(in)	y,
		real(kind=cfp), intent(in)	z,
		integer, intent(in)	l )

Purpose:

 !> Calculate the full set of real normalized solid spherical harmonics with l,m .le. L using recursion. See Helgaker, p.218 (Section 6.4) for details.
 !> For l=m=0: Slm=1.
 !>

Todo

{add error checking for case L > size(SH(,:))}

Parameters

[out]	SH	!> Real array (-L:L,0:L) containing the values of the solid spherical harmonics for all l .le. L and the corresponding values of m. !>
[in]	X,Y,Z	!> real input coordinates at which the solid harmonics will be evaluated. !>
[in]	L	!> Integer angular momentum of the last spherical harmonic to be generated. !>

cfp_sph_shell_to_cart_lshells()

subroutine, public special_functions_gbl::cfp_sph_shell_to_cart_lshells	(	integer, intent(in)	l,
		integer, dimension(:), intent(out)	nz,
		real(kind=cfp), dimension(:), intent(out)	c_nz,
		integer, dimension(:), intent(out)	nz_can )

This routine constructs for all real solid harmonic with L .le. l the matrix of coefficients for all M of the transformation from the cartesian harmonics (~x^i*y^j*z^k, i+j+k=L). On output the linear array c(:) emulates 2D matrix with 2*L+1 rows and (L+1)*(L+2)/2 columns. The rows of c correspond to the M values: -L,-L+1,...,0,1,...,L.
The coefficients in each row are ordered so that the n-th coefficient in the given row of c corresponds to the coefficient for the cartesian harmonic with the shell canonical index n.

Here is the call graph for this function:

cfp_sph_shell_to_cart_shell()

subroutine, public special_functions_gbl::cfp_sph_shell_to_cart_shell	(	integer, intent(in)	l,
		real(kind=cfp), dimension(:), intent(out)	c )

This routine constructs for a given real solid harmonic L the matrix of coefficients for all M of the transformation from the cartesian harmonics (~x^i*y^j*z^k, i+j+k=L). On output the linear array c(:) emulates 2D matrix with 2*L+1 rows and (L+1)*(L+2)/2 columns. The rows of c correspond to the M values: -L,-L+1,...,0,1,...,L.
The coefficients in each row are ordered so that the n-th coefficient in the given row of c corresponds to the coefficient for the cartesian harmonic with the shell canonical index n.

Here is the call graph for this function:

cfp_sph_to_cart_mapping()

subroutine, public special_functions_gbl::cfp_sph_to_cart_mapping	(	integer, intent(in)	l,
		integer, intent(in)	m,
		real(kind=cfp), dimension(:), intent(out), allocatable	c,
		integer, dimension(:), intent(out), allocatable	i_exp,
		integer, dimension(:), intent(out), allocatable	j_exp,
		integer, dimension(:), intent(out), allocatable	k_exp )

This routine constructs for a given real solid harmonic L,M the list of cartesian functions which build up this real solid harmonic. On output the array c(:) contains the coefficients with which the individual cartesians contribute to the solid harmonic. Exponents of the cartesians are then given in the arrays i_exp,j_exp,k_exp.

Todo

the construction of the coefficient list (the summations) should be included along the lines of sph_shell_to_cart_shell

Here is the call graph for this function:

cfp_zhar()

subroutine, public special_functions_gbl::cfp_zhar	(	real(kind=cfp), dimension(-l:l,0:l), intent(out)	sh,
		real(kind=cfp), intent(in)	x,
		real(kind=cfp), intent(in)	y,
		real(kind=cfp), intent(in)	z,
		integer, intent(in)	l )

Purpose:

 !> Calculate the full set of real unnormalized solid spherical harmonics with l,m .le. L using recursion. See Helgaker, p.210, p.218 (Section 6.4) for details.
 !> The unnormalized solid spherical harmonics are defined in Rico, Lopez, et al. Int. J. Q. Chem.,2012,DOI:10.1002/qua.24356.
 !> The mehod of calculation is to calculate the real solid spherical harmonics and then renormalize them to obtain the surface
 !> spherical harmonics using the formula:
 !>

\[ z_{lm}(x,y,z) = S_{lm}(x,y,z)\sqrt{\frac{1+\delta_{m,0}}{2}\frac{(l+|m|)!}{(l-|m|)!}}. \]

Todo

{rewrite the algorithm to calculate zlm directly using Helgaker's algorithm for the scaled solid harmonics rather than by calculating Slm first and then renormalizing}

{add error checking for case L > size(SH(,:))}

Parameters

[out]	SH	!> Real array (-L:L,0:L) containing the values of the real unnormalized solidspherical harmonics for all l .le. L and the corresponding values of m. !>
[in]	X,Y,Z	!> Real input coordinates for which the harmonics will be evaluated. !>
[in]	L	!> Integer angular momentum of the last harmonic to be generated. !>

Here is the call graph for this function:

ipair()

elemental integer function, public special_functions_gbl::ipair

(

integer, intent(in)

i

)

This function is used to index an ordered pair of values (i,j), where i .ge. j, i .ge. 1. The index of the ordered pair is: ipair(i) + j. This process of indexing can be used in a nested way to index quartets of integers, say (i,j,k,l). We compute ij = ipair(i)+j and kl = ipair(k)+l. The index of the quartet (i,j,k,l) is: ipair(ij)+kl. We assume that i.ge.j, k.ge.l, ij.ge.kl. This nesting (triangularization) is used heavilly to index the 2-particle symmetric integrals.

Here is the call graph for this function:

unpack_pq()

subroutine, public special_functions_gbl::unpack_pq	(	integer, intent(in)	pq,
		integer, intent(in)	n,
		integer, intent(out)	p,
		integer, intent(out)	q )

Assuming \( pq = p + (q-1)*n \) this routine returns p,q given pq,n.
